Axial fan,ball bearing

service life L10 at +40℃ (+104℉): min. 56,000h rotor metal

Connection

2 stranded wires, 300mm or 3-pole clamp for 2.5mm², clamping torque 0.8Nm max.

can be customer made according to customer’s requirement.

Enclosure cut-out

298×298⁺¹ mm

Mounting frame

can fix by fast fixing clip or fix by screws

Filter mat

F5

Filter material

new ABS material confirm to RoHS, fireproof or not fireproof can be choose

Operating/Storage temperature

-25 to +65℃ (-13 to +149℉) / -40 to +70℃ (-40 to +158℉)

Operating/Storage humidity

max. 75% RH (non-condensing)

Protection type/Protection class

IP55 / I (earthed)

FL323-F5

-

without fan

-

-

-

-

-

FFL323-F5-230A-C

230VAC

200×200×60

800/1000

400

48/63

0.23/0.28

63/66

FFL323A-F5-230B-C

230VAC

200×200×60

800/1000

480

48/63

0.23/0.28

63/66

FFL323A-F5-230C-C

230VAC

Ø220×60

800/1000

550

48/63

0.23/0.28

63/66

FFL323A-F5-230D-C

230VAC

225×225×80

1000/1150

700

72/80

0.33/0.35

63/66

FFL323-F5-230E-C

230VAC

280×280×80

1200/1400

850

120/160

0.5/0.7

65/70

FFL323-F5-115A-C

115VAC

200×200×60

800/1000

480

48/63

0.42

63/66

FFL323A-F5-115B-C

115VAC

200×200×60

800/1000

480

48/63

0.42

63/66

FFL323A-F5-115C-C

115VAC

Ø220×60

800/1000

480

48/63

0.42

63/66

FFL323A-F5-115D-C

115VAC

225×225×80

1000/1150

700

70/80

0.65/0.7

63/66

FFL323-F5-115E-C

115VAC

280×280×80

1200/1400

850

120/160

1/1/1.4

65/70

FFL323-F5-400A-C

400VAC

200×200×60

800/1000

400

60

0.2

63/66

FFL323A-F5-400B-C

400VAC

200×200×60

800/1000

480

60

0.2

63/66

FFL323A-F5-400C-C

400VAC

Ø220×60

800/1000

480

60

0.2

63/66

FFL323A-F5-400D-C

400VAC

225×225×80

1000/1150

700

72/80

0.2

63/66

FFL323-F5-400E-C

400VAC

280×280×80

1200/1400

850

120

0.36

65/70

FFL323A-F5-12-C

12VDC

200×200×60

1008

700

24

2

68

FFL323A-F5-24-C

24VDC

200×200×60

1008

700

24

1

68

FFL323A-F5-48-C

48VDC

200×200×60

1008

700

24

0.5

68
